DALI underground mining personnel carriers are offered with 6, 13, 18, 25 or 30 seats, with seat count customization noted on the current page. A 40-degree articulated frame, four-wheel drive and braking, Dana transmission components and a Deutz turbocharged engine support crew transport in mines and tunnels.
|
Selection Item |
Published Value |
|
Seating |
6 / 13 / 18 / 25 / 30 seats; customization listed |
|
Steering |
Articulated frame, 40-degree steering angle |
|
Engine |
Deutz turbocharged engine; model and power not published |
|
Transmission |
Dana gearbox and torque converter |
|
Drive / braking |
Four-wheel drive and four-wheel braking |
|
Brake type |
SAHR – spring applied, hydraulic release |
Chat With Us
Leave Message
This underground personnel carrier is intended for moving work crews through mine roadways and tunnel projects. The five published seating levels allow the vehicle to be discussed around shift size, but capacity must also be checked against roadway width, gradients, turning points, travel distance and boarding arrangements.
The page lists an ECS catalytic purifier with muffler. Exact engine, emissions and exhaust-treatment compliance must be confirmed for the destination market and mine rules.
Available 6-, 13-, 18-, 25- and 30-seat configurations cover different crew sizes. Ask for the seating drawing, access arrangement, restraints and allowable occupancy for the selected build.
The 40-degree articulated frame supports maneuvering through underground intersections. Vehicle dimensions and turning radius are not published, so the complete route still requires an engineering clearance check.
The current page lists a Deutz turbocharged engine, Dana gearbox and torque converter, front NO-SPIN differential and rear anti-slip configuration. These details should be confirmed model by model.
Four-wheel braking and SAHR service/parking brake integration are listed, together with alarms for oil temperature, oil pressure and the electrical system. Obtain the full braking and emergency-system specification before approval.
|
Parameter |
Published Value |
|
Seat quantity |
6 / 13 / 18 / 25 / 30; customization listed |
|
Steering angle |
40 degrees |
|
Operator structure |
Ergonomic canopy listed |
|
Brake system |
Combined service and parking brake; SAHR |
|
Differentials |
Front NO-SPIN; rear anti-slip |
|
Monitoring |
Oil-temperature, oil-pressure and electrical-system alarms |
Choose around the largest regular crew, required supervision space, route clearance and boarding workflow. Request a layout drawing before confirming capacity.
The page does not say. Obtain the dimensions, weight and turning radius for the exact seating configuration.
No market-specific approval is stated on the page. Confirm passenger-vehicle, mine-safety, emissions and fire-protection requirements locally.
Provide seat count, tunnel profile, gradients, route length, shift schedule, destination country and required safety options.
